gas heater pilot burner with CSA

FOB Reference Price:Get Latest Price
US $1.5-2 / Piece | 500 Piece/Pieces (Min. Order)
Supply Ability:
300000 Piece/Pieces per Month
Port:
Ningbo/Shanghai/Hangzhou
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
JIALI
Model Number:
ODS03
Certificate:
CSA,CE, ISO9001
Material:
copper,ceramic,thermocouple
Usage:
Household
Applicance:
gas oven,gas heater, outdoor heaters
Application of gas:
LPG,Propane,Butane,NG
Purpose:
we make the fire safety for people
Feature:
Eco-Friendly
Function:
ignition for gas
Packaging & Delivery
Packaging Details
cartons (as your request)
Delivery Time
10-25Days











Product Description



  gas heater pilot burner with CSA

For this ODS ignition system we design for the gas heater ,normally we design according to customer's requirement .

In nowadays people use gas more and more , we are the company who can help people to keep safe when they use gas for heating ,

cooking .here you can check our different types of ODS product







Technical parameter

Heating characteristic

≥12mV (within 20s at 650°C)

Cooling characteristic

≤1.5mV(within 60s)

Range of length

150mm(5.9inch)~ 1800mm(71inch)

Range of resistance

(10~50)±3 mΩ



Operating conditions:

Range of ambient temperatures:   0°C ~ 52°C (32°F to 125°F)



Maximum operating temperatures:

Thermocouple Tip:750ºC / 1382°F

Thermocouple Wire:180ºC / 356°F

Cold Junction:150 ºC / 302°F                             Injector(Burner):750ºC / 1382°F





1,Working principle: ODS use thermocouple component as a sensor to search the temperature of pilot flame

in order to drive the electromagnetic valve,when the space is hypoxia(O-17%~19%),

the flame temperature is under 400°C,there is not enough potential to open the valve ,

so then the valve will be closed to keep safe .

2,Function: automatic ignition for gas appliance ,hypoxia protection.

3,Air source :NG,LPG

4,Output Potential: ≥12MV.

5,Injector : stainless steel/ruby/copper.

6,All design and production are may according to customer’s demand.





  gas heater pilot burner with CSA



                                            Technical parameters

  Applicable gas species

 LPG,NG,Propane & Butane

  CO2

 0.8%-1.5%

  O2

 ≥19.0%

  CO

 ≤50ppm

  Inner resistance

 5-50±3 mΩ

  No-load potential

 ≥20mV(650)

  Connector

 Nut (M8*1,M9*1) or others

                    Axial tension 50N, sustain 1 min, no loose, no cut

                             The length according the client’s request



               Other Types



Packaging & Shipping



  gas heater pilot burner with CSA



PACKING & SHIPPING

PCS/BOX

25pcs/box

BOX/CTN

8box/ctn   200pcs/ctn

CTN SIZE

400*250*300 mm

SHIPPING

By courier &By sea & By air

DELIVERY

10-25 days











Company Information

About JIALI

Ningbo JiaLi Gas Appliance & Science and Technology Co., Ltd. was established in 1998, specializes in  manufacturing of gas appliance,

such as: Thermocouple,ODS,Thermostat,Magnet valve etc.

In 2009,company  through  the  ISO9001, and our thermocouple passed the CSA.
In 2011, ERP system & ISO (matching the ERP)  began to be applied to fully guarantee products' quanlity and efficient internal management. Meanwhile,
 we have a number of outstanding engineers and perfect laboratory, which make sure that we can prodcue great products.
 Furthermore, our ODS has 5 patents,and passed the CSA by one-time. Especially,the shut-off point of our ODS products can be controlled within 0.3% (CO2, for example 0.8~1.1%).








Our Services



1.Inquiry response:Your inquires will be replied in 24hours.


2.Samples support:Two free samples are avaliable in 2-5days.


3.Delivery time:Your shipment will be loaded in 15-25days,depeds on quantity.

More details, please contact Annie,thanks!
